1200W 48V 20A Waterproof Split-type Wireless Charger
Suitable for four-way shuttle robots
Overview
The 1200W waterproof split-type wireless charger is developed by Qingdao Luyu Energy Technology Co., Ltd. for four-way shuttle vehicles.
It supports wireless charging for material-handling robots and other mobile robots that require waterproof or moisture-resistant charging. It enables automatic, unattended robot charging while reducing maintenance effort and improving operational safety.
Technical Data
Electrical Parameters
| Rated Power | 1200W |
|---|---|
| Input Voltage | AC176-264V |
| Charging Voltage | 35-60V |
| Charging Current | 20A |
| Max Efficiency | ≥87% |
| Working Distance | 0-20mm (coil A)；0-50mm (coil B) |
| Offset Tolerance | long axis 20mm short axis 10mm (coil A)；long axis 60mm short axis 10mm (coil B) |
| Charging Management | CC-CV |
| Over-temperature Protection | Yes |
| Output Over-current Protection | Yes |
| Output Over-voltage Protection | Yes |
| Transmitter Communication | RS485*1 |
| Receiver Communication | RS485*1 |
| Alarm and Charging Status | Indicator alarm |
| RF Communication Frequency | 2.4GHZ |
| Temperature Range | -40~55℃ |
| Humidity Range | 0-85% |
| Storage Temperature | -40~70℃ |
| Transmitter Protection Rating | IP67 |
| Receiver Protection Rating | IP67 |
Mechanical Parameters
| Transmitter Size (L*W*H) | transmittersize: 273mm*131mm*45mm；transmitter coil : 150mm*100mm*32mm (coil A), 190mm*170mm*35mm (coil B) |
|---|---|
| Receiver Size (L*W*H) | receiversize: 150mm*100mm*50.5mm；receiver coil : 150mm*100mm*32mm (coil A), 160mm*140mm*28mm (coil B) |
| Transmitter Weight | transmitter: 1.5kg；transmitter coil : 1.3kg (coil A), 2.2kg (coil B) |
| Receiver Weight | receiver: 0.6kg；receiver coil : 1.3kg (coil A), 1.8kg (coil B) |
Key Features
Contactless charging, no risk of electric shock
Designed for special industrial environments where equipment needs automatic charging with less manual maintenance.
Suitable for various harsh environments
Designed for special industrial environments where equipment needs automatic charging with less manual maintenance.
No manual connection required for unattended operation
Designed for special industrial environments where equipment needs automatic charging with less manual maintenance.
