Suitable for four-way shuttle transport robots
The waterproof 3000W split wireless charger is a product independently developed by Qingdao Luyu Energy Technology Co., Ltd. and is suitable for four-way shuttle cars.
It can be applied to wireless charging of handling robots and other types of mobile robots that require waterproofing and moisture-proofing. It can realize automatic charging and unmanned operation of the robots, reduce maintenance costs, and be safe and convenient to use.
| Rated Power | 3000W |
|---|---|
| Input Voltage | AC176-264V |
| Charging Voltage | 40-60V |
| Charging Current | 50A |
| Max Efficiency | ≥85% |
| Working Distance | 0-20mm (coil A)；0-40mm (coil B) |
| Offset Tolerance | long axis 10mm short axis 10mm (coil A)；long axis 60mm short axis 10mm (coil B) |
| Charging Management | CC-CV |
| Over-temperature Protection | Yes |
| Output Over-current Protection | Yes |
| Output Over-voltage Protection | Yes |
| Transmitter Communication | RS485*1 |
| Receiver Communication | RS485*1 |
| Alarm and Charging Status | Indicator alarm |
| RF Communication Frequency | 2.4GHZ |
| Temperature Range | -40~60℃ |
| Humidity Range | 0-85% |
| Storage Temperature | -40~70℃ |
| Transmitter Protection Rating | IP67 |
| Receiver Protection Rating | IP67 |
| Transmitter Size (L*W*H) | transmittersize: 301.5mm*140mm*60mm；transmitter coil : 220mm*120mm*25mm (coil A), 250mm*180mm*28mm (coil B) |
|---|---|
| Receiver Size (L*W*H) | receiversize: 210mm*130mm*50mm；receiver coil : 220mm*120mm*25mm (coil A), 220mm*160mm*25mm (coil B) |
| Transmitter Weight | transmitter: 2kg；transmitter coil : 1.7kg (coil A), 3kg (coil B) |
| Receiver Weight | receiver: 1.2kg；receiver coil : 1.7kg (coil A), 2.3kg (coil B) |
For equipment charging needs in special working conditions and complex industrial environments, improving automatic charging and unattended operation.
